Description
Our Job Box Caster Kits are designed to add mobility to your tool storage, whether it's Greenlee, Knaack, or some other brand, we've got you covered. This 4" Job Box Caster Kit features 4" polypropylene plastic casters, 2 rigid and 2 swivel. The kit is complete with hardware and instructions. Product comes with 3/8"-16 x 1" Carriage Bolts with Flange Nuts.
Product Details
Part Number:
4X2 CASTER KIT (VALUE LINE) - KIT 3
SKU
953001
Series:
45 Series - 2" Wide (to 1250 lb/ea)
Raceway Type:
Dual Ball Swivel Raceways For Smooth Swivel and Strength
Brake:
None
Load Capacity:
500 lb
Mounting Height:
5.63 in
Wheel Diameter:
4 in
Wheel Tread Width:
2 in
Wheel Description:
Polypropylene HD
Wheel Color:
Black
Wheel Bearing:
Roller
Wheel Profile:
Flat Tread
Wheel Hardness:
70(+/-5) Shore D
Wheel Thread Guards:
None
Fastening:
4" x 4-1/2" top plate
Bolt Hole Pattern:
2-5/8" x 3-3/8" slotted to 3" x 3"
Plate Bolt Size Recommended:
3/8"
Swivel Radius:
3.38 in
Finish:
Zinc Plated
Axle Size:
1/2" diameter with zerk fitting
Operating Temperature Range:
-20F° to +180F°
Mfg:
4X2 E-LINE POD 2 SWIVEL AND 2 RIGID; Kit 3 Hardware
Warranty:
1 year
Conformity:
RoHS compliant zinc plating, tested to ANSI ICWM:2012 standards for capacity and durability, NSF listed component
